Color steel tile crusher

Applicable materials: all kinds of scrap metal cans, paint buckets, scrap metal, color steel tiles, iron briquette, scrap aluminum, scrap steel, scrap copper, motorcycle racks, bicycle racks, scrap home appliances, car shells, carriage boards, keels strips, rolling gates, scrap angle iron, etc.

Color Steel Tile Crusher Machine Waste Scrap Color Steel Tile Crushing Recycling Equipment

【product details】
The color steel tile crusher is carefully developed on the basis of absorbing the advantages of a variety of crushers, fully using the theory of impact, shearing, striking, grinding, etc., and the material size is regular, the bulk density is high, and it is easy to sort to form fine materials, which is convenient for Recycling in iron and steel plants.
【Application Materials】
Color steel tiles, scrap steel plates, paint buckets, car oil filters, car shells, cans, iron sheets, etc.
【Power】18.5-220kw
【Production】600-12000kg/h

Product Description
Color steel tile crusher is a new type of equipment specially designed for crushing color steel tiles. On the basis of absorbing the advantages of various crushers, this series of color steel tile crushers make full use of the theory of impact, shearing, striking and grinding. carefully developed. The color steel tile crusher has the advantages of high output, low energy consumption, high efficiency, and uniform discharge.

The color steel tile crusher production line system is equipped with a dust removal device, which reduces the pollution hazards such as dust and paint skin generated in the production process, and the produced metal particles have the characteristics of good quality and high density. The color steel tile crusher has the characteristics of low noise and pollution. Small, easy to operate, easy to maintain, reasonable in design and elegant in appearance, the size of the feeding inlet can be modified according to the user's needs, never returning the material, and causing no personal injury.

Applications: Widely used in scrap steel recycling companies, metal smelting, construction industry, metal recycling industry, environmental protection recycling industry, waste home appliance recycling, automobile recycling companies, etc.

Applicable materials: all kinds of scrap metal cans, paint buckets, scrap metal, color steel tiles, iron briquette, scrap aluminum, scrap steel, scrap copper, motorcycle racks, bicycle racks, scrap home appliances, car shells, carriage boards, keels strips, rolling gates, scrap angle iron, etc.

Performance characteristics
1. The blade of the color steel tile crusher is a meshing blade made of high alloy, which has a good crushing effect on any high-hardness material;
2. The color steel tile crusher is driven by a geared motor, which saves 20% of the electricity than other can crushers;
3. The color steel tile crusher starts smoothly without too much noise, and the foundation is installed, and the noise is very small;
4. The color steel tile crusher has a strong structure and densely clothed stiffening plates to ensure the strength of the box;
5. The color steel tile crusher can be equipped with conveyor belt feeding equipment, which expands the scope of processing and recycling, with high value space and convenient transportation.

Working principle
The color steel tile crusher is a processing method that uses a crusher to crush color steel tiles, and uses a sorting system to sort the crushed materials to obtain pure high-quality scrap steel. Under the continuous drive, the hammers on the rotor of the crusher take turns hitting the scrap steel into the cavity. Under the strong impact, the materials are torn and extruded into crushed materials of corresponding specifications, and then processed by the sorting equipment, which can be obtained. High-quality crushed metal with high purity. The color steel tile crusher is equipped with a screen at the bottom of the crushing cavity, and the size of the screen mesh determines the size of the discharge.

Model8001000130016001800
Mainframe Floor StandChannel steel fabricationChannel steel fabricationChannel steel fabricationChannel steel fabricationChannel steel fabrication
Size (MM)2200*1600*28002400*1750*28003300*2520*40504770*3860*47505600*2500*4800
Thickness of mainframe steel plate (MM)20mm20mm50mm50mm50mm
Host motor45-55KW75KW*1132KW*1110kw*2 of 200KW*1315KW*1
Rotor diameter (MM)400mm500mm600mm730mm1000mm
Hammerhead16 handles (fierce steel) each weighing 12KG16 handles (fierce steel) each weighing 12KG24 handles (fierce steel) each weighing 25KG24 handles (fierce steel) each weighing 28KG16 handles (fierce steel) weighing 45KG each.
Spindle material40CrMo40CrMo40CrMo40CrMo40CrMo
Sieve materialMn13Mn13Mn13Mn13Mn13
Screen thickness (MM)50508080120
Electric Motor BlockChannel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)
Infeed conveyor500*7M500*7M800*4M1200*10M1400*12M
Discharge Conveyor500*4M500*4M600*6M800*5M1000*6M
Magnetic Separation Conveyor500*3M500*3M600*5M800*5M1000*6M
Starter cabinetStar-delta startStar-delta startStar-delta startStar-delta startStar-delta start

Delivery and Transportation:
Wooden crate packing can protect wood shredder, tire shredder from dust, moisture and corrosion.
Excellent logistics team to ensure the machine is safely delivered to customer's warehouse with no extra charge from export or import customs.

Hai Shi Hong Service
Pre-sales: Provide fitted solution and offer to customers, is able to adjust the layout of complete line to fit customers working area, also provide technical support 24 hours service online.
After sales:Hai Shi Hong skilled technicians are experienced at oversea installation, therefore they are available to assist with onsite installation, commissioning & training on request. Layout drawing, circuit diagram and maintenance manual will be provided together with our products after sales, so that ensure customers have plenty of time to get prepared for installation.
Wearing parts support:Hai Shi Hong has widely built extensive cooperation with wearing parts partner manufacturers more than 14years, has ability to continuously provide wearing parts and after-sale service to global market.
