Motorcycle scrap crusher

Applicable materials: bicycle frame, motorcycle frame, color steel tile, carriage board, keel strip, color TV, refrigerator, washing machine, scrap angle steel, scrap square tube, filing cabinet, safe, car slot, packing block, electrical shell, cans , beer cans, cans, Sprite cans, Lulu cans, paint buckets, bicycles, motorcycles, car shells, color steel tiles, scrap angle iron, rolling shutters, iron boxes, etc.

Motorcycle Crusher

【product details】
The motorcycle crusher is an advanced fine crushing equipment, which is carefully developed on the basis of absorbing the advantages of various crushers and fully utilizing the theory of impact, shearing, mutual impact and grinding.
【Application Materials】
Bicycle frame, motorcycle frame, color steel tile, carriage board, keel strip, etc.
【Power】18.5-220kw
【Production】600-12000kg/h

Product Description
The motorcycle crusher is mainly composed of a car crusher, a production line, a magnetic separation device, a conveyor, and a motor. Never return material, will not cause harm.
When working, the material can be fully and effectively crushed in the crushing cavity, with high output, low energy consumption, high efficiency, and uniform discharge. It is mainly used for scrap metal crushing equipment such as bicycle frames, motorcycle frames, color steel tiles, carriage boards, keel bars and so on.

Applicable materials: bicycle frame, motorcycle frame, color steel tile, carriage board, keel strip, color TV, refrigerator, washing machine, scrap angle steel, scrap square tube, filing cabinet, safe, car slot, packing block, electrical shell, cans , beer cans, cans, Sprite cans, Lulu cans, paint buckets, bicycles, motorcycles, car shells, color steel tiles, scrap angle iron, rolling shutters, iron boxes, etc.

Prospects for development: As various major steel countries have issued decrees to restrict the export of steel, the supply of steel is very tight, which can be said to be a crisis in the steel industry. But the understanding of the word "crisis" should be excavated from another depth. "Crisis" is the coexistence of danger and opportunity. If you know where the opportunities are and how to seize them, you can open up a new future for yourself. Take the current scrap steel processing industry as an example, because of the shortage of steel, the price of scrap steel will rise. Generally speaking, in the next few years, motorcycle The development trend of the car crusher will be the coexistence of "crisis" and "opportunity".

Performance characteristics
1. The motorcycle crusher blade is a meshing blade refined with high alloy, which has a good crushing effect on any high hardness material;
2. The motorcycle crusher is installed with a foundation, and the startup is stable without too much noise;
3. The motorcycle crusher uses an automatic operation cabinet, which has a high degree of automation and saves manpower;
4. The motorcycle crusher has a sturdy structure and densely clothed stiffening plates to ensure the strength of the box.

Working principle
The motorcycle crusher uses the basic principle of hammering. Driven by a high-speed and high-torque motor, the hammers on the rotor of the main engine take turns to hit the objects to be crushed that enter the cavity, and pass through the space formed between the lining plate and the hammer. , the material to be crushed can be fully and effectively crushed in the crushing cavity, and the material to be crushed can be torn into pieces that meet the specifications. There is a dust removal device, which reduces the harm of dust pollution in the production process. The equipment mainly has the advantages of high output, low energy consumption, high efficiency, and uniform discharge of finely divided materials. In addition, the equipment has low noise, low pollution and simple operation during use. , easy maintenance.

Model8001000130016001800
Mainframe Floor StandChannel steel fabricationChannel steel fabricationChannel steel fabricationChannel steel fabricationChannel steel fabrication
Size (MM)2200*1600*28002400*1750*28003300*2520*40504770*3860*47505600*2500*4800
Thickness of mainframe steel plate (MM)20mm20mm50mm50mm50mm
Host motor45-55KW75KW*1132KW*1110kw*2 of 200KW*1315KW*1
Rotor diameter (MM)400mm500mm600mm730mm1000mm
Hammerhead16 handles (fierce steel) each weighing 12KG16 handles (fierce steel) each weighing 12KG24 handles (fierce steel) each weighing 25KG24 handles (fierce steel) each weighing 28KG16 handles (fierce steel) weighing 45KG each.
Spindle material40CrMo40CrMo40CrMo40CrMo40CrMo
Sieve materialMn13Mn13Mn13Mn13Mn13
Screen thickness (MM)50508080120
Electric Motor BlockChannel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)Channel steel fabrication (thickened)
Infeed conveyor500*7M500*7M800*4M1200*10M1400*12M
Discharge Conveyor500*4M500*4M600*6M800*5M1000*6M
Magnetic Separation Conveyor500*3M500*3M600*5M800*5M1000*6M
Starter cabinetStar-delta startStar-delta startStar-delta startStar-delta startStar-delta start

Delivery and Transportation:
Wooden crate packing can protect wood shredder, tire shredder from dust, moisture and corrosion.
Excellent logistics team to ensure the machine is safely delivered to customer's warehouse with no extra charge from export or import customs.

Hai Shi Hong Service
Pre-sales: Provide fitted solution and offer to customers, is able to adjust the layout of complete line to fit customers working area, also provide technical support 24 hours service online.
After sales:Hai Shi Hong skilled technicians are experienced at oversea installation, therefore they are available to assist with onsite installation, commissioning & training on request. Layout drawing, circuit diagram and maintenance manual will be provided together with our products after sales, so that ensure customers have plenty of time to get prepared for installation.
Wearing parts support:Hai Shi Hong has widely built extensive cooperation with wearing parts partner manufacturers more than 14years, has ability to continuously provide wearing parts and after-sale service to global market.
